MAIN FEATURES

  • Modular crowd barrier system made of AISI 304 steel.
  • Easy to fit together, and works well alongside turnstiles, mechanical turnstiles and swivel gates - alone, they help convey people flows or mark off areas for different uses.

A complete range for completing any system configuration

OUR RANGE

Columns for joinable crowd barriers

001PSTRV

Galvanizes steel column with chrome-finish plastic fastening-flange and cover, without holes. H = 1,000 mm.

    001PSTRV2F

    Galvanized steel riser with chromed plastic anchoring flange and flange cover, with two holes. H = 1,000 mm.

      001PSTRV4F90

      Galvanized steel riser with chromed plastic anchoring flange and flange cover, with two + two holes at 90°. H = 1,000 mm.

        001PSTRV4F180

        Galvanized steel riser with chromed plastic anchoring flange and flange cover, with two + two holes at 180°. H = 1,000 mm.

          001PSTRV6F

          Galvanized steel riser with chromed plastic anchoring flange and flange cover, with six holes. H = 1,000 mm.

            001PSTRV8F

            Galvanized steel riser with chromed plastic anchoring flange and flange cover, with eight holes. H = 1,000 mm.

              001PSTRVX

              Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with no holes. H = 1,000 mm.

                001PSTRVX2F

                Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with two holes. H = 1,000 mm.

                  001PSTRVX4F90

                  Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with two + two holes at 90°. H = 1,000 mm.

                    001PSTRVX4F180

                    Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with two + two holes at 180°. H = 1,000 mm.

                      001PSTRVX6F

                      Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with six holes. H = 1,000 mm.

                        001PSTRVX8F

                        Riser plus anchoring flange and flange cover made of AISI 304 stainless steel, with eight holes. H = 1,000 mm.

                          Tubes and couplers for joining crowd barriers

                          001PSTRT050

                          AISI 304 steel, horizontal tubeØ 40 mm, thickness 1 mm, L = 500 mm.

                            001PSTRT100

                            AISI 304 steel, horizontal tubeØ 40 mm, thickness 1 mm, L = 1,000 mm.

                              001PSTRT150

                              AISI 304 steel, horizontal tubeØ 40 mm, thickness 1 mm, L = 1,500 mm.

                                001PSTRT200

                                AISI 304 steel, horizontal tubeØ 40 mm, thickenss 1 mm, L = 2,000 mm.

                                  001PSTRM001

                                  Two sleeve couplers made of chromed plastic with fastening screws.

                                    001PSTRM003

                                    Two sleeve couplers made of AISI 304 steel with fastening screws.

                                      001PSTRM004

                                      Two, wall-attaching couplers made of AISI 304 steel with fastening screws.

                                        Mono-directional crowd barriers for trolley transit

                                        001PSTPC100

                                        Crowd barrier with two arches.L = 1,000 mm, H = 1,000 mm.

                                          001PSTPC150

                                          Crowd barrier with three arches.L = 1,500 mm, H = 1,000 mm.

                                            001PSTPC200

                                            Crowd barrier with four arches.L = 2,000 mm, H = 1,000 mm.

                                              Complete crowd barriers

                                              001PSTRFPA

                                              Floor-anchored crowd barrier made of AISI 304 steel and 6 mm-thick polycarbonate panel. H = 900 mm.

                                                001PSTRFPAN

                                                Floor-anchored crowd barrier made of AISI 304 steel without panel. H = 900 mm.

                                                  Crowd barriers with anti-panic handle

                                                  001PSUS120D

                                                  Crowd barrier made of AISI 304 steel.Right-hand post L = 1,200 mm, H = 1,000 mm.

                                                    001PSUS120S

                                                    Crowd barrier made of AISI 304 steel.Left-hand post L = 1,200 mm, H = 1,000 mm.

                                                      001PSUS090D

                                                      Crowd barrier made of AISI 304 steel.Right-hand post L = 900 mm, H = 1,000 mm.

                                                        001PSUS090S

                                                        Crowd barrier made of AISI 304 steel.Left-hand post L = 900 mm, H = 1,000 mm.

                                                          Joinable crowd barriers

                                                          001PSTRV80

                                                          Riser made of AISI 304 steel with no clips.H = 900 mm, Ø 80 mm.

                                                            001PSTRV802F

                                                            Riser made of AISI 304 steel with two clips.H = 900 mm, Ø 80 mm.

                                                              001PSTRV804F090

                                                              Riser made of AISI 304 steel with two + two clips at 90°.H = 900 mm, Ø 80 mm.

                                                                001PSTRV804F180

                                                                Riser made of AISI 304 steel with two + two clips at 180°.H = 900 mm, Ø 80 mm.

                                                                  001PSTRV806F

                                                                  Riser made of AISI 304 steel with six clips.H = 900 mm, Ø 80 mm.

                                                                    001PSTRV808F

                                                                    Riser made of AISI 304 steel with eight clips.H = 900 mm, Ø 80 mm.

                                                                      001PSTRSFPL60875

                                                                      Transparent, 6-mm thick, polycarbonate panel.L = 750 mm, H = 800 mm.
