Gates automation / Swing gate operators / FROG / 001FROG-A24

001FROG-A24

FROG-A24

Irreversible underground 24 V gearmotor with adjustable leaf-closing for swing gates with up to 3.5 m leaves that weighs up to 400 kg.

Catalogue

Depliant

Manuals and Certifications

Technical data			Value
Max. length of leaf (m)	3.5	2.5	2
Max. weight of leaf (kg)	400	600	800

24 V

Gearmotor or automation with encoder.

Automation tested in compliance with European standards regarding impact forces.

24 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

36 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

48 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

120 V AC gearmotor for US markets.

230 V AC gearmotor.

230-400 V AC three-phase gearmotor for industrial use. It guarantees greater inspiration in the starting phase.

Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.

Product designed to house the 806SS-0040 plug-in card from the RIO System 2.0 series.

Product compatible with CXN BUS 2-wire connection technology.

Product equipped with BRUSHLESS technology.

From the house to the condominium, the X1 system is able to satisfy any need regarding the number of internal extensions, the distances involved in the system and the management of the entrance panels.

From a single home to a large residential complex, the XIP system combines simplicity of installation and coverage of large distances. Both access control management and concierge services are integrated into the system.

The IP360 system uses Ethernet distribution as the main structure for communication, guaranteeing an almost infinite extension of the system. It overcomes all the limits of traditional video door entry systems, allowing maximum freedom of configuration.

The 4G system allows you to establish a connection with the called number thanks to the 4G network over unlimited distances. It is ideal in all applications where it is impossible to lay cables, allowing the installation of devices without any wiring, since it is sufficient to supply only the power supply.

The 200 system is characterized by great versatility: all the functions that can be implemented in the system are implemented by coding on the same two conductors that carry the audio signal. The System 200 also provides only direct current power, which guarantees immunity from disturbances and buzzes on the audio.

001U1990ML

Anta fino a 3,5 m e peso fino a 400 kg

001FROG-A24

24 V irreversible underground gearmotor with adjustable leaf stop for swing gates up to 3.5 m and 400 kg

001FROG-CFN

Steel foundation box with cataphoresis treatment.

001A4366

Release device with customized key and EURO-DIN cylinder.

801QA-0060

230 V AC multifunction control panel for 24 V double-leaf swing gates with graphic display, self-diagnosis and management of advanced technologies

001AF43S

433,92 MHz plug-in radio frequency card.

001DIR10

Pair of 12 – 24 V AC – DC outdoor photocells

806LA-0040

Wall-fastening base for KRX.

806LA-0020

LED flashing light with power supply from 24 V AC – DC up to 230 V AC

806TS-0270

Four-channel 433.92 MHz rolling code transmitter

4228003000

Antenna cable L = 5 m.

8K01MI-006

Anta fino a 3,5 m e peso fino a 400 kg

001FROG-A24

24 V irreversible underground gearmotor with adjustable leaf stop for swing gates up to 3.5 m and 400 kg

001FROG-CFN

Steel foundation box with cataphoresis treatment.

001A4364

Release device with lever key.

801QA-0060

230 V AC multifunction control panel for 24 V double-leaf swing gates with graphic display, self-diagnosis and management of advanced technologies

001AF43S

433,92 MHz plug-in radio frequency card.

001DIR10

Pair of 12 – 24 V AC – DC outdoor photocells

806LA-0020

LED flashing light with power supply from 24 V AC – DC up to 230 V AC

806TS-0270

Four-channel 433.92 MHz rolling code transmitter

Technical data

Dato tecnico	Valore
Power supply to motor (V)	24 DC
Absorption (A)	15 Max.
Power (W)	180
Maneuvering time at 90° (s)	ADJUSTABLE
Duty/cycle (%)	HEAVY-DUTY SERVICE
Operating temperature (°C)	-20 ÷ +55
Protection rating (IP)	67

Operational limits

Technical data			Value
Max. length of leaf (m)	3.5	2.5	2
Max. weight of leaf (kg)	400	600	800

Complete your solution

Control panels

801QA-0050

Multifunction control panel, with 230 V AC power supply, for 24 V double-leaf swing gates, with programming and signaling display, self-diagnosis of safety devices, Adaptive Speed & Torque Technology, CXN BUS, 2 safety inputs and storage of up to to 250 users.

24 V
CAME Connect
Encoder
RIO System 2.0
EN Tested
CXN BUS

801QA-0060

Multifunction control panel, with 230 V AC power supply, for 24 V double-leaf swing gates, with graphic programming and signaling display, self-diagnosis of safety devices, Adaptive Speed & Torque Technology, CXN BUS, 4 safety and storage inputs up to 1000 users.

24 V
CAME Connect
Encoder
RIO System 2.0
EN Tested
CXN BUS

Foundation boxes

001FROG-CFNI

AISI 304 steel foundation box, complete with release latching-lever, gate fastening brace, slots for fastening to post, and screw for adjusting the opening limit-switch point.

001FROG-CFN

Stainless steel, cataphoresis treated foundation box, featuring release transmission, gate fastening brace, slots for fastening to post, and spring for adjusting the opening limit-switch point.
