Access Control Gateways
- Gateways dedicated to access control, for both residential and commercial properties. These gateways enable users to manage entry systems, such as keypads, RFID readers ensuring secure and efficient access to the property. All the parameters can be easily set and manage through the CAME CONNECT Web Portal. CAME’s access control gateways offer different connectivity protocols such as Wi-Fi, ethernet and GSM.
Our range
-
806SA-0180
QBEMFSAC
Ethernet – Wi-Fi gateway compatible with the CAME Connect system
- CAME Connect
-
806SA-0170
RGSM001AC
GSM Gateway module with built-in radio compatible with the CAME CONNECT system
- 24 V
- CAME Connect
-
806SA-0200
WIFI GATEWAY FOR ACCESS
Wi-Fi AC Gateway compatible with the CAME Connect system
- CAME Connect
Main characteristics
- Developed with CONNECT technology for remote management of temporary access via gateway
- Automated system for access via smartphone
- Keypad code management via cloud for opening doors in common areas or for unconnected guests
- Extension of access management to CAME automations
- Installation freedom by choosing the appropriate type of connection (Wi-Fi – Ethernet – GSM)
- Secure management of personal data
Technical data
| Models | Power supply (V) | Power supply to motor (V) | Power (W) | Current draw (A) | Max. current draw (A) | Max. power supply (V) | Current draw at 24 V (mA) | Crown turns (rpm) | Duty/cycle (%) | Force (N) | Max. maneuvering speed (m/min) | Maneuvering time at 90° (s) | Cycles/hour | Manouvering speed (m/min) | Pinion module | Reduction ratio (i) | IP Protection rating | Operating temperature (°C) | Storage temperature (°C) | Motor’s heat protection (°C) | Length (mm) | Package dimensions (mm) | Weight (kg) | Torque (Nm) | Rpm speed (turns/min) | Weight lifted (kg)* | Duration of operation (min) | Combinations | Radio signal frequency (Mhz) | Batteries | Material | Bluetooth Radio Frequency (GHz) | Maximum speed measured at the end of the leaf (m/min) | Product standards | Compliance with directives | Max. current draw (mA) | Wireless Standard | Casing material | Operating relative humidity (%) | Temperature reading precision (°C) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 806SA-0180 | 5 DC | 30 | +5 ÷ +40 ÷ | ÷ | 869,50 | x | 802.11b, 802.11g, 802.11n | |||||||||||||||||||||||||||||||||
| 806SA-0170 | 12-30 AC – DC | 3 | -20 ÷ +70 ÷ | ÷ | 869,50 | x | Polycarbonate Composite | |||||||||||||||||||||||||||||||||
| 806SA-0200 | 2,5 | 30 | -20 ÷ +70 ÷ | ÷ | x | 2,4 | Polycarbonate Composite |
