Gates automation / Garage doors automations / VER / 801MV-0060

801MV-0060

VER08DES

Automation with encoder, complete with electronic board with segment graphic display, for sectional doors and overhead doors.

Catalogue

Depliant

Manuals and Certifications

MODELS	-\|24v–801MV-0060\|-
Max. surface of the door (m²)	12

24 V
Encoder
EN Tested

Gearmotor or automation with encoder.

Automation tested in compliance with European standards regarding impact forces.

24 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

36 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

48 V DC gearmotor suitable for intensive service. It guarantees operation even in the event of a blackout.

120 V AC gearmotor for US markets.

230 V AC gearmotor.

230-400 V AC three-phase gearmotor for industrial use. It guarantees greater inspiration in the starting phase.

Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.

Product designed to house the 806SS-0040 plug-in card from the RIO System 2.0 series.

Product compatible with CXN BUS 2-wire connection technology.

Product equipped with BRUSHLESS technology.

From the house to the condominium, the X1 system is able to satisfy any need regarding the number of internal extensions, the distances involved in the system and the management of the entrance panels.

From a single home to a large residential complex, the XIP system combines simplicity of installation and coverage of large distances. Both access control management and concierge services are integrated into the system.

The IP360 system uses Ethernet distribution as the main structure for communication, guaranteeing an almost infinite extension of the system. It overcomes all the limits of traditional video door entry systems, allowing maximum freedom of configuration.

The 4G system allows you to establish a connection with the called number thanks to the 4G network over unlimited distances. It is ideal in all applications where it is impossible to lay cables, allowing the installation of devices without any wiring, since it is sufficient to supply only the power supply.

The 200 system is characterized by great versatility: all the functions that can be implemented in the system are implemented by coding on the same two conductors that carry the audio signal. The System 200 also provides only direct current power, which guarantees immunity from disturbances and buzzes on the audio.

8K01MV-021

Surface up to 12 m²

801MV-0060

Automation with encoder and segment graphic display for sectional and overhead doors

001TOP-432EE

Two-channel multiuser transmitter

001AF43S

433,92 MHz plug-in radio frequency card.

8K01MV-018

Surface up to 12 m²

801MV-0060

Automation with encoder and segment graphic display for sectional and overhead doors

000CHAINGUIDES

Guida a catena in tre pezzi L = 3,02 m

806TS-0270

Four-channel 433.92 MHz rolling code transmitter

001AF43S

433,92 MHz plug-in radio frequency card.

8K01MV-017

Surface up to 12 m²

801MV-0060

Automation with encoder and segment graphic display for sectional and overhead doors

806TS-0270

Four-channel 433.92 MHz rolling code transmitter

001AF43S

433,92 MHz plug-in radio frequency card.

Technical data

MODELS	-\|24v–801MV-0060\|-
Protection rating (IP)	20
Power supply (V – 50/60 Hz)	230 AC
Power supply to motor (V)	24 DC
Power (W)	150
Duty/cycle (%)	20
Cycles/Hour	10
Operating temperature (°C)	-20 ÷ +55
Manouvering speed (m/min)	8
