Automation gateways
- The Automation Gateways, powered by CONNECT technology, provide remote control of automated operators from any location, with the option for local management via CAME KEY.
- We offer installation freedom with Wi-Fi, Ethernet or GSM connections and the possibility of extending the system via slave modules (806SA-0040 – 806SA-0150).
- The system enables full control of operator commands, status, and programming via the CAME protocol, while also supporting scenario creation and timers for customized automation.
- End users can manage the system through the CAME AUTOMATION App, while professional installers have access to more advanced settings and configurations via the CAME SETUP App.
Our range
-
806SA-0130
QBEMFSB2
Ethernet-Wi-Fi gateway to control up to 5 slave modules
- CAME Connect
-
806SA-0140
WIFI GATEWAY
Gateway to connect the operator to the cloud or to use as a bluetooth selector
- CAME Connect
-
806SA-0010
RGSM001
GSM Gateway module with radio
- 24 V
- Connect
-
806SA-0020
RGSM001S
Standalone GSM Gateway module
- 24 V
- CAME Connect
Main characteristics
- Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.
- Freedom of installation by choosing the appropriate connection type (Wi-Fi-Ethernet-GSM).
- Possibility to extend the system using slave modules (806SA-0040 – 806SA-0150).
- Thanks to the CAME protocol it is possible to have total control of the operator (commands, automation status, programming).
- Possibility to program scenarios and timers, easily and intuitively.
- Thanks to two output relays and two digital inputs, integrated in the unit, the operator opening or closing can be controlled without the CAME protocol (806SA-0010 – 806SA-0020).
- The basic GSM version without built-in radio-frequency module is also available (806SA-0030).
- CAME AUTOMATION APP and CAME SETUP can be freely downloaded from Google Play or App Store.
Technical data
| Models | Power supply (V) | Power supply to motor (V) | Power (W) | Current draw (A) | Max. current draw (A) | Max. power supply (V) | Current draw at 24 V (mA) | Crown turns (rpm) | Duty/cycle (%) | Force (N) | Max. maneuvering speed (m/min) | Maneuvering time at 90° (s) | Cycles/hour | Manouvering speed (m/min) | Pinion module | Reduction ratio (i) | IP Protection rating | Operating temperature (°C) | Storage temperature (°C) | Motor’s heat protection (°C) | Length (mm) | Package dimensions (mm) | Weight (kg) | Torque (Nm) | Rpm speed (turns/min) | Weight lifted (kg)* | Duration of operation (min) | Combinations | Radio signal frequency (Mhz) | Batteries | Material | Bluetooth Radio Frequency (GHz) | Maximum speed measured at the end of the leaf (m/min) | Product standards | Compliance with directives | Max. current draw (mA) | Wireless Standard | Casing material | Operating relative humidity (%) | Temperature reading precision (°C) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 806SA-0130 | 5 DC | 30 | +5 ÷ +40 ÷ | ÷ | 869,50 | x | 802.11b, 802.11g, 802.11n | |||||||||||||||||||||||||||||||||
| 806SA-0140 | 2,5 | 30 | -20 ÷ +70 ÷ | ÷ | x | 2,4 | Polycarbonate Composite | |||||||||||||||||||||||||||||||||
| 806SA-0010 | 12 – 30 AC – DC | 3 | -20 ÷ +70 ÷ | ÷ | 869,50 | x | Polycarbonate Composite | |||||||||||||||||||||||||||||||||
| 806SA-0020 | 12-30 AC – DC | 3 | -20 ÷ +70 ÷ | ÷ | x | Polycarbonate Composite |
