Specification

• Power: Standard 380V AC 3-Phase 50/60 Hz, 2,2 - 11 kW motor (varies depending on blocker size).
• Operating with 24V DC in case of power failure is optionally available.
• Control Pack: 24V DC powered PLC control unit is placed in power unit cabinet.
• 24V DC (opt.12V DC / 220V AC) solenoids.
• Operating Temperature: -5°C / +55°C (opt. -30°C / +70°C
• Speed: Standard operation ~3 - 5 sec. (ascend/descend) depending on road blocker dimensions.
• Fast raise up (EFO, by optional hydraulic accumulator) ~1 - 1,5 sec. and may differ depending on road blocker dimensions for road blockers wider than 4,0 m.

Optional Accessories

• Telescopic front panels
• Hydraulic accumulator for  EFO-fast raise up
• 24V DC motor in case of power failure ( min. 60-100 movements )
• Oil heater (for oil tank)
• Oil cooler

A wide selection of additional accessories is available.

HPU – Hydraulic Power Unit

In the power unit the two systems (hydraulic and electrical) are separated to make easier and safer the maintenance operations; input and output dry contacts are available to manage the Road Blocker
