FTX

Solution for applying in private homes and apartment buildings, on small and medium-sized gate posts

Gate leaves up to 2 m

MAIN FEATURES

Encoder-based movement control.
Control board with terminal blocks, display and storage for up to 250 users.
Set up for operation in case of power outage.
Self-diagnosing safety devices.
User-friendly release lever for manually opening the gate.
Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.

Three versions, all with encoder control, one with a short arm for C-Max 150 distance, and one with a long arm for C-Max 250 distance.
Smooth and silent movement with opening time of 20-30 seconds at 90°.
The operator can be managed from a remote location via app through the CAME GATEWAY.
Built-in user-friendly release tab protected by key for manually opening the gate.
On-board ZL65 control board, with separate terminals, and display, for easier start-ups and diagnoses.
Plug-in connectors for RIOCN8WS, R700, R800, RSE and AF receiver cards.

Easy to apply mechanical stops.
It works even during power outages by fitting emergency batteries in the specific housing.
It is set up to connect to the wireless Rio safety system.

MODELS	801MB-0110					801MB-0050					801MB-0120
LEAF OPENING (°)	A	B	D	E	C Max.	A	B	D	E	C Max.	A	B	D	E	C Max.
90	140	420 (490 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	250 (300 with item 801XC-0070)	140	420 (490 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	150 (300 with item 801XC-0070)	140	420 (490 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	250 (300 with item 801XC-0070)
90	160 ÷ 180	380 (460 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	250 (300 with item 801XC-0070)	160 ÷ 180	380 (460 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	150 (300 with item 801XC-0070)	160 ÷ 180	380 (460 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	250 (300 with item 801XC-0070)
110	200 ÷ 220	400 (470 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	50 (300 with item 801XC-0070)	200 ÷ 220	400 (470 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	50 (300 with item 801XC-0070)	200 ÷ 220	400 (470 with item 801XC-0070)	Min. 150	310 (410 with item 801XC-0070)	50 (300 with item 801XC-0070)

TECHNICAL CHARACTERISTICS

MODELS	801MB-0110	801MB-0050	801MB-0120
Protection rating (IP)	44	44	44
Power supply (V - 50/60 Hz)	230 AC	-	-
Power supply to motor (V)	24 DC	24 DC	24 DC
Absorption (A)	4 Max.	4 Max.	4 Max.
Power (W)	140	140	140
Maneuvering time at 90° (s)	from 20 to 30	from 20 to 30	from 20 to 30
Cycles/Hour	40	40	40
Thrust (N)	180	180	180
Operating temperature (°C)	-20 ÷ +55	-20 ÷ +55	-20 ÷ +55

OUR RANGE

Complete operators with 24 V DC gearmotors, tested in compliance with regulatory standards EN 12453 - EN 12445

801MB-0110

FTX20DLC - Irreversible 24 V gearmotor featuring a control board with functions display, on-board radio decoding and hinged transmission arm with C Max. 250 mm for swing gates with up to 2 m leaves that weighs up to 200 kg. RAL7024-grey cover.

Download FASCICOLO FTX20DGC/DLC MULTI4 A5 (IT, EN, FR, RU)
Download FTX conformity declaration (CE)

24 V DC gearmotors, tested in compliance with regulatory standards EN 12453 - EN 12445

801MB-0050

FTL20DGS - Irreversible 24 V operator with hinged transmission arm for swing gates with Max. C of 150 mm with leaves up to 2 m long that weighs up to 200 kg. RAL7024-gray cover.

Download FASCICOLO FTX20DGS/FTX20DLS MULTI4A A3R (IT, EN, FR, RU)
Download FTX conformity declaration (CE)

801MB-0120

FTX20DLS - Irreversible 24 V gearmotor with hinged transmission-arm with C Max. 250 mm for swing gates with up to 2 m leaves that weighs up to 200 kg. RAL7024-grey cover.

Download FASCICOLO FTX20DGS/FTX20DLS MULTI4A A3R (IT, EN, FR, RU)
Download FTX conformity declaration (CE)
