OPERATIONAL LIMITS

Ideal solution for applying in private homes and industrial plants

G2080Z
G2080IZ
G2080E
G2080IE
G2080EZ
G2180ZS
G2180ZU
G2180Z
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
  • Max. net clearance width (m)7,6
TECHNICAL DATA
MODELS G2080Z G2080IZ G2080E G2080IE G2080EZ G2180ZS G2180ZU G2180Z
Protection rating (IP) 54 54 54 54 54 54 54 54
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 230 AC 230 AC 120 AC 120 AC 120 AC
Power supply to motor (V) 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC
Absorption (A) 15 Max. 15 Max. 15 Max. 15 Max. 15 Max. 15 Max. 15 Max. 15 Max.
Power (W) 300 300 300 300 300 300 300 300
Opening time at 90° (s) 4 ÷ 8* 4 ÷ 8* 4 ÷ 8* 4 ÷ 8* 4 ÷ 8* 4 ÷ 8* 4 ÷ 8* 4 ÷ 8*
Duty/cycle (%) HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE HEAVY-DUTY SERVICE
Torque (Nm) 600 600 600 600 600 600 600 600
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55

OUR RANGE

Barriers with 24 V DC gearmotor and built-in control panel

001G2080Z

Galvanized, painted steel and set up for fitting accessories.

Download FASCICOLO G2080Z / G2080IZ MULTI04 A4 (IT, EN, FR, RU)
Download G2080Z conformity declaration (CE)
Download GARD 8 conformity declaration (CE ROHS)

001G2080IZ

Barrier made of satin-coated AISI 304 stainless steel, set up for fitting accessories.

Download FASCICOLO G2080Z / G2080IZ MULTI04 A4 (IT, EN, FR, RU)
Download G2080Z conformity declaration (CE)
Download GARD 8 conformity declaration (CE ROHS)

001G2080E

Barrier with encoder, made of painted, galvanized steel and set up to take accessories.

Download FASCICOLO G2080E - G2080IE MULTI4 A4 (IT, EN, FR, RU)
Download G2080E conformity declaration (CE)

001G2080IE

Barrier with encoder, made of AISI 304 satin-finish stainless steel, set up to take accessories.

Download G2080E conformity declaration (CE)

001G2080EZ

Barrier with encoder, made of painted, galvanized steel and set up to take accessories.

Download FASCICOLO G2080EZ MULTI A4 (IT, EN, FR, RU)
Download G2080EZ conformity declaration (CE)

120 V AC barriers with 24 V DC gearmotor and built-in control panel

001G2180ZS

Painted galvanized-steel barrier ready to fit accessories, fitted with boom-position signalling via 1 A max - 24 V DC clean contacts.

001G2180ZU

Galvanized, painted steel and set up for fitting accessories.

Download FASCICOLO G2180IZU / G2180ZU EN (USA English)

001G2180Z

Galvanized, painted steel and set up for fitting accessories.

Download FASCICOLO G2080Z / G2080IZ MULTI04 A4 (IT, EN, FR, RU)

Accessories for: 001G2080E - 001G2080IE - 001G2080EZT

002RSE

Interface card for controlling two operators or for enabling the Came Remote Protocol.

Download FASCICOLO RSE MULTI (IT, EN, FR, DE, ES, NL)
Download RSE conformity declaration (CE)

    001R700

    Control board for decoding and access-control management via transponder selector.

      001R800

      Control board for decoding and access-control management via keypad selectors.

      Download R800 conformity declaration (CE)

        Accessories for: 001G2080Z - 001G2080IZ - 001G2180Z - 001G2180ZS

        002LB38

        Circuit board for emergency operation and battery charging.

        Download FASCICOLO LB38 MULTI4A A3R (IT, EN, FR, RU)
        Download LB38 conformity declaration (CE)
        Download LB38 conformity declaration (CE ROHS)

        Accessories for: 001G2080E - 001G2080IE - 001G2080EZT

        002LB39

        Circuit board for emergency operation and battery charging.

        Download FASCICOLO LB39 MULTI4A A3R (IT, EN, FR, RU)
        Download LB39 conformity declaration (CE)
        Download LB39 LBEM40 conformity declaration (CE ROHS)

        Balancing springs

        001G02040

        Balancing spring Ø 40 mm.

          001G04060

          Balancing spring Ø 50 mm.

            001G06080

            Balancing spring Ø 55 mm.

              Accessories

              001G02801

              Integrated, dome flashing light.

              Download FASCICOLO G02801 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)
              Download G02801 conformity declaration (CE)
              Download G02801 conformity declaration (CE ROHS)

                001G02802

                Support for fitting DIR-series photocells.

                Download FASCICOLO G02802 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                  001G02805

                  Rack for housing the emergency batteries.

                  Download FASCICOLO G02805 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                    001G02000

                    White painted, tube-section aluminum boom, with groove covering profile. Ø 100 mm, boom length: 2 m.

                      001G04000

                      White painted, tube-section aluminum boom, with groove covering profile. Ø 100 mm, boom length: 4 m.

                        001G06000

                        White painted, tube-section aluminum boom, with groove covering profile. Ø 100 mm, boom length: 6 m.

                          001G028401

                          Yellow luminous cord with white LEDs.

                          Download FASCICOLO G028402 MULTI4A A4 (IT,EN, FR, RU)
                          Download G028401 conformity declaration (CE)
                          Download G028401 conformity declaration (CE ROHS)

                            001G028402

                            Cable for connecting the luminous cord.

                            Download FASCICOLO G028402 MULTI4A A4 (IT,EN, FR, RU)

                              001G0465

                              Painted aluminum skirt (modules L = 2 m).

                              Download FASCICOLO G0465 MULTI00 A6

                                001G02807

                                Fixed rest.

                                Download FASCICOLO G02807 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                                  001G02808

                                  Swing rest.

                                  Download FASCICOLO G02808 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                                    001G02809

                                    Package of 20 red, reflective, adhesive strips.

                                      001G028011

                                      Detaching boom fastener.

                                      Download FASCICOLO G028011 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                                        001PSRT01

                                        Heater kit with thermostat.

                                        Download FASCICOLO PSRT01 MULTI4A A3 (IT, EN, FR, RU)

                                          Accessories for: 001G06000

                                          001G06802

                                          Required for passage clearances of over 4 m.

                                          Download FASCICOLO G06802 / G06850 MULTI (IT, EN, DE, FR, ES, NL)

                                            Accessories for: 001G04000

                                            001G06803

                                            Boom joint, with inner reinforcement.

                                            Download FASCICOLO G06803 MULTI (IT, EN, FR, DE, ES, NL, PT, PL, RU)

                                              001G028401

                                              Yellow luminous cord with white LEDs.

                                              Download FASCICOLO G028402 MULTI4A A4 (IT,EN, FR, RU)
                                              Download G028401 conformity declaration (CE)
                                              Download G028401 conformity declaration (CE ROHS)

                                                001G028402

                                                Cable for connecting the luminous cord.

                                                Download FASCICOLO G028402 MULTI4A A4 (IT,EN, FR, RU)

                                                  803XA-0240

                                                  Red/green LED strip for booms up to 6.5 m long.

                                                    803XA-0250

                                                    Red/green LED strip for booms up to 8 m long.
