Key Features

  • 316 Marine Grade Stainless Steel
  • Engraved in Red
  • Galvanized Back Box and Flush Fitted (Bezel)
  • Surface Mount Back Box available with Stainless Steel or Red Powder Coated Stainless Steel Finish
  • Double Pole Switch
  • Closed Contact to Break Power to Lock
  • Open Contact to Trigger Door Release Timer
  • FS4 Drop Key Also Available
Technical Specifications
Bezel (mm) 156W x 156H x 68D
Bezel Cut out (mm) 118W x 118H x 65D
Surface Mounted (mm) 118W x 118H x 73D
Switching Double pole switch with NO & NC pre-wired connections
Rating Max 5A @ 250VAC
Operating Temperature -200°C ~ +550°C
Mechanical Life 1,000,000 Cycles
Contact Material Gold
Fixings 4 x M4 Stainless Steel Security Screws
Accessories FS4 Drop Key / Security Allen Key

Downloads

FIRE FIGHTER SWITCHES DATASHEET
FS/MTLOCK/BZ DATASHEET

Compatible Products

Apex

Ideal for developments with multiple apartments
