Buttons |
Plastic tactile function buttons |
|
Large 20mm door release button |
Door Release |
Momentary, Illuminated Green LED |
Privacy |
Momentary, Illuminated Red LED |
|
6 timeout settings (5mins to 12hrs) |
|
Can also be disabled or set to latch on/off |
Call Tone |
Pulsed Tone with Volume Adjustment |
|
Muted call tone when privacy on |
Volume |
84dB SPL Max (at 1 metre) |
Operating Voltage |
12-15VDC (13.8V Nominal) |
Power |
~0.01W Idle, 2.6W Active |
Power Consumption |
190mA during call tone |
|
9mA per lit LED (Privacy and/or Door Open) |
Connections |
8 Way Screw Terminals |
Cable |
CAT5 / CW1308 4 pair minimum (leaves 1 spare core) - Note: 3 pair can be used if Door Open LED function omitted |
Dimensions |
(WxHxD) 96 x 206 x 49mm (approx. not including cable) |
